KS2 compact control unit
KS2 compact controller from Wildeboer
The KS2 compact controller from Wildeboer automates the control of ventilation components such as fire dampers or fans in a very simple yet highly reliable way. It can be housed centrally in a control cabinet to save space. This is particularly advantageous in buildings with limited space.
Software and commissioning
With clear software interfaces, e.g. supported by automated assistance programs, the desired building configuration can be commissioned and implemented quickly and safely. This gives users maximum security in the areas of planning and operation as well as full cost transparency in all phases of the project!
The connected modules are identified automatically, which saves a lot of time. Functional tests of fire dampers can be safely scheduled, automated and documented, e.g. using calendar control.
Trigger groups and sequential controls
The connected components can be summarised in trigger groups, for example on the basis of a fire matrix, in order to carry out defined actions. Sequential controls for fire and smoke dampers or for fans can also be easily implemented.
The KS2 compact control unit can be seamlessly combined with the BS2 bus control unit to enable the smooth networking of different systems within a ventilation and air conditioning system.
Control of fire protection and ventilation components with the KS2 compact control unit
As part of the overall Wildeboer-Net system, the KS2 compact control unit supports the control and monitoring of fire protection and ventilation components in buildings. It offers a wide range of connection options, such as
- Fire dampers with spring return actuators or thermal-mechanical release device with 230 V AC bzw. 24 V AC/DC
- Fire protection valves
- Smoke protection dampers with spring return actuator with 230 V AC bzw. 24 V AC/DC
- Smoke release devices
- Multileaf dampers with spring return actuators with 230 V AC bzw. 24 V AC/DC
- Ventilation systems/fans
- Sensors and actuators
- Building management system and/or fire alarm centre
Moduls KS2 compact control unit
Kompaktsteuerung KS2
System für die automatische Steuerung raumlufttechnischer Komponenten
Frequently Asked Questions about the KS2 compact control unit
The KS2 compact control unit and the BS2 fieldbus system are used to control and monitor fire dampers and to integrate smoke detection devices. They enable the monitoring of damper positions and the carrying out of functional tests. Using the WiNet-SW-02 software, it is possible, amongst other things, to configure trigger groups, sequence controls, fan enable functions and calendar-based controls, as well as to carry out and document functional tests.
The KS2 compact control unit enables centralised, space-saving and clearly organised control of fire dampers, as well as the integration of smoke detection devices. It supports the automatic identification of connected modules. The WiNet-SW-02 software can be used to configure functional tests, calendar-based controls, trigger groups, sequence controls and fan authorisations. The software-based parameterisation, the automatic identification of connected modules and the pre-wired, ready-to-connect design within the control cabinet reduce the overall effort required for engineering, installation and commissioning.
A maximum of 48 fire dampers can be connected to a KS2 compact control unit. Depending on the version, the pre-configured KS2 control cabinet solutions are designed for up to 24 fire dampers and are available either for 24 V DC actuators or for 230 V AC actuators. In the case of a control cabinet assembled by the customer, the individual motor modules can be used for fire dampers with either 24 V DC or 230 V AC actuators.
The KS2 compact control system is installed in a control cabinet. It is also possible to install several control cabinets within a building and connect them to one another via the Wildeboer-Net. It is particularly suitable when fire dampers, smoke dampers, louvre dampers, smoke detectors or fans are to be clearly organised within one or more compact control systems.
The BS2 bus control system is a decentralised, modular fieldbus system. The modules can be mounted close to the components and communicate via the BS2 fieldbus. This makes both the BS2 and KS2 equally suitable for spatially distributed ventilation and air-conditioning systems with numerous components, trigger groups and sequential control systems.
KS2 and BS2 can also be combined with one another within the Wildeboer-Net. This allows centralised and decentralised control concepts to be implemented together within a single system.
Yes. The BS2 fieldbus system and the KS2 compact controller can be combined. Both systems can be networked within the Wildeboer-Net and operated and configured across the system using the WiNet-SW-02 software. This allows centralised and decentralised control areas within a ventilation and air-conditioning system to be mapped together.
